ERTE B2 - Configuration; Adjustment (Calibration) switch

B2 WEIGHING INDICATOR
4 Configuration
4.1 Adjustment (Calibration) switch
A toggle switch located on main pcb determines the mode of configuration. If the switch is in “LOCKED”
position, it is not possible to alter weighing related settings. If the switch is in “UNLOCKED” position, it
is possible to edit weighing parameters and adjustment data.
v1.00 Page 8
USER MANUAL
Main board
Display board
Keypad board
Connectors
INTERNAL VIEW
