3 INTRODUCTION
The Caddy 140 and Caddy 200 are two transistor controlled rectifiers designed for
welding with coated electrodes and for TIG welding (touch start).
The advanced electronics provide rapid control response, low power demand and
excellent welding characteristics. Inverter technology contributes to low weight and
compact dimensions of the units. T he rounded slimline shape of the unit makes it
comfortable to carry. The strap can be folded to serve as a carrying handle, or fully
extended to serve as a shoulder strap.
4 TECHNICAL DESCRIPTION
Caddy is equipped with a remote control socket which activates automatically when
a remote control device is connected. NOTE! The contact pins L and M must be
strapped in the remote device’s connection cable for automatic activation to function.
Theinverterissuppliedwitha3meterlongmainscable.
Caddy is delivered with 5 meter long welding and return cables. These are attached
to cable connectors allowing quick change of polarity.
The manufacturer’s serial number is stamped on the rating plate.
ESAB’s accessories for the product can be found on page 11.
4.1 Tecnical data
Caddy 140 Caddy 200
Performance:
at 35% duty cycle
at 60%
at 100%
140A/26 V
110A/24 V
80A/23 V
200A/28 V
150A/26 V
115A/25 V
Setting range continuously variable
3--140A
continuously variable
5--200A
Open circuit voltage 50--80 V 50--80 V
Mains supply:
voltage
primary current
fuse
mains cable, area
230 V
22A
16A*
3x1,5 mm
2
400 V
10A
16A
4x1,5 mm
2
Enclosure class IP 23 IP 23
Application class
Weight approx. 11 kg approx. 11 kg
*When welding below 100A a 10A slow fuse is adequate.
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
