3 INTRODUCTION
The ESABMig 405 and ESABMig 505 are step switched power sources designed for
MIG/MAG–welding together with wire feed units ESABFeed 30, ESABFeed 48
and the most of ESAB wire feeders.
The power units are fan–cooled and equipped with thermal overload protection.
The machines can be fitted with an instrument for display of current and voltage. It
incorporates a hold function and can be calibrated.
The machines can be fitted with a flow guard.
ESAB’s accessories for the product can be found on page 203.
3.1 Equipment
The power source is supplied with:
S Return cable 5m with return clamp
S Shelf for gas cylinder
S Guide pin for wire feed unit
S Instruction manual
4 TECHNICAL DATA
ESABMig 405
Voltage 400–415V, 3~50/60 Hz 230/400–415/500V 3~50 Hz
230/440–460 3~60Hz
Permissible load
at100 % duty cycle 280 A/28 V 280 A/28 V
at 60 % duty cycle 365 A/32 V 365 A/32 V
at 50 % duty cycle 400 A/34 V 400 A/34 V
Setting range (DC) 50A/16,5V–400A/34V 50A/16,5V–400A/34V
Open circuit voltage 17–45 V 17–45 V
Open circuit power 360 W 360 W
with cooling unit 600 W 600 W
Efficiency at max current 71% 71%
Power factor at max current 0,98 0,98
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Dimensions lxwxh 812 x 552 x 925 812 x 552 x 925
Weight 144 kg 145 kg
with cooling unit 158 kg 158 kg
Operating temperature –10 to +40
o
C –10 to +40
o
C
Enclosure class IP 23 IP 23
