– 59 –
405,505e
ESABMig 505
Voltage 400–415V, 3~50/60 Hz 230/400–415/500V 3~50 Hz
230/440–460 3~60Hz
Permissible load
at100 % duty cycle 390 A/33,5 V 390 A/33,5 V
at 60 % duty cycle 500 A/39 V 500 A/39 V
Setting range (DC) 50A/16,5V–500A/39V 50A/16,5V–500A/39V
Open circuit voltage 17–50 V 17–50 V
Open circuit power 440 W 440 W
with cooling unit 620 W 620 W
Efficiency at max current 82% 82%
Power factor at max current 0,92 0,92
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Dimensions lxwxh 812 x 552 x 925 812 x 552 x 925
Weight 214 kg 215 kg
with cooling unit 228 kg 229 kg
Operating temperature –10 to +40
o
C –10 to +40
o
C
Enclosure class IP 23 IP 23
Application classification
Duty cycle
The duty cycle refers to the time as a percentage of a ten–minute period that you can weld at a cer-
tain load without overloading.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
5 INSTALLATION
The installation must be executed by a professional.
WARNING!
This product is intended for industrial use. In a domestic environment this product may cause radio
interference. It is the user’s responsibility to take adequate precautions.
The power supply should be lifted by means of its lifting
eye. The handle is only intended for pulling it along the
ground.
Lifting instructions
GB
