SECTION 2 DESCRIPTION
2.1 Introduction
2.2 General Specications
ESP 200 Power Console, p/n 36974
OUTPUT (100 % duty cycle) Voltage 160VDC
Current range DC 50A to 200A
Power 8000 W to 32000 W
Open Circuit Voltage (OCV) 325VDC
INPUT Voltage (3-phase) 200/230/380/415/460/575 Volts
Current (3- phase) 115/100/60/55/50/40 Amperes
Frequency 50/60Hz
KVA 39.8 kW
Power 37.8 kW
Power Factor 95%
Input Fuse Rec. See Section 3, Installation, page 3-3
The ESP 200 Power Console is designed for plasma mechanized or hand cutting applications. It can be used with other ESAB
products such as the PT-26 and PT-600 torches, an optional plumbing box and a remote set-up pendant.
50 to 200 Amperes cutting current range •
Forced air cooled •
Solid state DC power •
Integral water cooler •
Input voltage protection •
Local or remote front panel control •
Thermal switch protection for main transformer and power semiconductor components •
LED status troubleshooting •
380/415V CE Mains Supply ........................................................S
sc min
6.8MVA
...................................................................................................................... Z
max
0.025Ω
380/415V CE Mains Supply, S
sc min
Minimum short circuit power on the network in accordance with IEC61000-3-12.
380/415V CE Mains Supply, Z
max
Maximum permissible line on the network impedance in accordance with IEC61000-3-11.
