SECTION 7 REPLACEMENT PARTS
Item No Qty Part Number Description Circuit Symbol
1 3 950760 Relay Enclose DPDT 24 VAC 10A K4,5,6
2 1 2080196 Relay Enclose 3PDT 120VAC K3
3 1 673168 Terminal Block 13pos 20A TB4
4 5 2234521 Plug – 16pos P4,5,6, Mod1 P1,
Mod2 P1
5 1 952252 Sensor --Current TD1
6 3 2234520 Plug – 8pos P3, Mod1 P2,
Mod2 P2
7 2 2234891 Plug – 10pos Mod1 P3,4,
8 2 2234891 Plug – 10pos Mod2 P3,4
9 5 2234521 Plug – 16pos P4,5,6, Mod1 P1,
Mod2 P1
10 1 673458 Contactor – Pilot Arc 3 pole 40A K2
11 2 9 51161 Capacitor – Metpoly 20uf 120VDC C1,C2
12 3 2234520 Plug – 8pos P3, Mod1 P2,
Mod2 P2
13 3 2234518 Recpt 16pos J3
3 2234520 Plug – 8pos P3, Mod1 P2,
Mod2 P2
14 1 36351 Board – Terminal Output
15 3 2234519 Recpt 16pos J4,5,6
3 2234521 Plug – 16pos P4,5,6, Mod1 P1,
Mod2 P1
16 1 58V58 Adapter B/I—G F ¼ NPTM BKHD
17 1 33033 Adapter B/A-W M ¼ NPTM BKHD
18 1 997830 Recpt 5 Pole J1
19 1 36909GY Box – High Frequency
20 1 950823 Snap Bushing
21 1 837302 Reactor Assembly H.F. T3
22 1 836431 Spark gap Assembly SG
23 1 58v75 Adapter, B/A-W ¼ NPTM BKHD
24 1 634090 Adapter, C/A-W F ¼ NPTM Cable
