SECTION 7 REPLACEMENT PARTS
Item No Qty Part Number Description Circuit Symbol
1 1 36349 Auto XFMR T2
2 1 17315247 Resistor 4.7K OHM 12W R6
3 1 950627 Capacitor 4200uf 350VAC C3
4 2 951109 Housing Contact 12pos J9,10
2 2062367 Recpt Housing 12pos nylon P9,10
5 1 673676 Fan Blade
6 1 2062334 Motor --Fan M1
7 1 952002 Core -- Saturable L1
8 1 38094 PCB Isolation Amp PCB1
9 2 950101 Housing –Contact Crimp 4 pin PCB1 P9,5
1 952034 Plug 5pos PCB1 P10
3 952030 Plug 18pos PCB1 P1,3,4
10 1 952032 Plug 16pos PCB1 P2
1 950096 Housing, Contact Crimp 3 pin PCB1 P7
11 2 952013 Caster --Swivel
12 1 952179 Water Tank
13 2 952012 Caster -- Fixed
14 5 994471 Clamp – Hose W/D .5OD X 1.06 D SS
15 1.25ft 90858007 Tubing Braided 5/8 ID
16 3.67ft 90858625 Tubing, Vinyl Clear 5/8 ID
17 1.25ft 90858007 Tubing Braided 5/8 ID
18 1 952182 Spout Remote Filler
19 1 952181 “Y” plastic pipe
20 3 156F05 Plasma torch coolant 1 gallon (3.8 L)
21 Reference Restart Switch Assembly –Ref. CE units only
22 1 674553 Relay Enclosed, TD10 DPDT 120 VAC K8
23 1 37671 BRKT Restart Sel Mod
24 1 13735310 Relay enclosed, DPDT 24VDC K7
25 1 950826 Term Block 5 POS 20A TB6
1 2062197 Marker Strip 5 POS
26 1 673213 SW, SPST, TGGL S7
27 1 2062367 Recpt. Housing 12 POS nylon P10
1 951109 Housing Contact, 12 POS J10
