49
* Photo shows optional Digital Volt/Ammeter Module, P/N 32857, and Spot/Stitch/Anti-Stick Control Module, P/N 32858.
• Was 97W63, changed to 950769, 6/95.
ITEM QTY PART CKT.
NO. REQ. NO. DESCRIPTION (Figure 6.1) DESIG.
2 1 33188YL PANEL, SIDE, RIGHT
3 1 950769• STRAIN,RELIEF,BUSHING
5 2 1373 0623 LATCH, DOOR
6 1 33192M PLATE, BLANK COVER*
7 1 33291YL COVER, HINGED
8 1 33189M PANEL, CONTROL, SILKSCREENED
10 1 33187YL PANEL, SIDE, LEFT
11 1 2360 3918 POTENTIOMETER, 1K, WIRE SPEED CTRL, 2W R1
12 1 950584 KNOB
13 1 32818 SWITCH, FINE VOLTS ADJ., 8 POS. S1
14 2 2062171 KNOB
15 1 647233 RECEPTACLE, 8 PIN J3
16 2 2062171 KNOB w/ SET SCREW
17 1 32902 SWITCH, COARSE VOLTS ADJ., 3 POS, HI-MED-LO S2
18 1 951069 PLUG, PLASTIC "C" SIZE (RED)
19 1 680552 ADAPTOR, POWER & GAS (SPOOL GUN)
20 1 950721 SWITCH, TOGGLE, (ON/OFF) S3
21 1 21165 GUIDE TUBE OUTLET (035/045) (ts into conn. tube, 6" lg)
22 1 952924 TORCH ADAPTOR ASSY. includes:
1 2361 2350 POWER LUG
1 2361 0696 ADAPTOR BLOCK ASSY (fem trigger pins/gas hose/2 wires)
1 2361 0528 HOUSING, GUN ADAPTOR (STRAIGHT) - molded blk plast
1 23612590 CONNECTION TUBE, 4" LG BRASS
23 1 33190 BUSBAR, COPPER
24 1 82F31 WORK CLAMP
25 2 13730912 WHEEL
NOT SHOWN
1 13735895 AXLE
4 64304275 WASHERS
2 99510614 COTTER PINS
1 951574 CYLINDER CHAIN
26 2 950396 CASTER, SWIVELS 5"
27 1 951672 HANDLE (From (1/1/94)
950695 HANDLE (Before 1/94)
28 1 0558001651 GUNMASTER 250cc 12'
1 0558001652 GUNMASTER 250cc 15'
29 1 13732313 BUSHING
30 1 SET SCREW
31 1 34886 CABLE AND CLAMP
32 1 2091514 WARNING LABEL
33 1 13734588 LABEL
34 1 13736753 WELD PARAMETER LABEL
SECTION 6 REPLACEMENT PARTS
