51
ITEM QTY. PART CKT.
NO. REQ. NO. DESCRIPTION (Figure 6.2) DESIG.
1 1 33184M BASE
4 1 672225 INSULATOR STANDOFF
5 1 1373 6750 TRANSFORMER, MAIN - for 208/230 v. model T1
1 33176 TRANSFORMER, MAIN - for 208-575 v. model T1
6 1 951634 VALVE, SOLENOID, 24 V(from 1/1/94) SOL1
1373 0628 VALVE, SOLENOID 24 V (before 1/94)
7 1 951633 CONNECTOR, "Y" from 1/1/94)
2360 6726 HOSE CONNECTION (before 1/94)
8 7 1373 2230 CAPACITOR 10,000 MT, 50V & screws #10-32 C 1-7
12 3 1373 0222 BUSHING
14 1 31484 P.C. BOARD, SPEED CONTROL PCB1
15 1 2360 8111 TERMINAL BLOCK, 8 PT 230 V TB1
16 1 1373 5940 MARKER, TERMINAL
17 2 950760 RELAY (from 1/1/94 to present) K2, K3
*suggest 0558007736 3dpt 24 vac 10A
2361 0322 RELAY, 4 PDT, 24 VAC, 10A (prior to 1/1/94)
KUP 11A55-24
KUP 17A55-24
18 1 1373 0469 BRIDGE, RECTIFIER BR1
19 1 952173 CONTACTOR 60 amp 24V coil K1
------------------------------------------------------HISTORY------------------------------------------
2 0558001290 CONTACTOR 60 amp E Busbar
952173 CONTACTOR FURNAS 42EF35A3L 2 7/8 x 3 11/16
2 13730665 CONTACTOR 40 amp E Busbar
13734781 CONTACTOR FURNAS 42CF35A3L 2 1/4 x 2.90
20 2 0558001290 BUSBAR “E” STAMPING
21 1 9951 2178 RESISTOR, 50 OHM, 50W R3
22 1 2360 9967 TERMINAL, 3 POS TB3
23 3 674216 CAPICATOR .02uf 1KV C9-11
24 1 1373 5289 RESISTOR 1 OHM 25W R5
25 1 1373 1989 THERMOSTAT 145° TS1
26 1 951649 POWERCORD
27 1 13736733 HEATSHRINK RECTIFIER
1 90862175 3/4" HEATSHRINK TUBING
28 1 33818 BUSBAR (9.94")
AR 2132496 INSULATION (sold by FT)
29 1 13731597 SLOPE RESISTOR (2 pcs per side)
30 1 31563 SHUNT
31 2 23610005 END BOARD
32 1 950253 BRACKET
33 1 13736749 BUSBAR (13")
34 1 13731780 P/C CONN TO PCB1
35 1 13736752 COMPLETE HARNESS
36 1 33817 BUSBAR (16")
SECTION 6 REPLACEMENT PARTS
Capacitor C9-11 and R5 resistor were added 4/93 (starting with Serial No. B93H36548) to provide greater relay protection.
