ESAB MXH 300PP - Ordering Number; Wear Parts

MXH 300 PP/400w PP
© ESAB AB 2005
Wear parts
- 16 -
bg17we
Pos Denomination Ordering number Notes
1 Steel liner Ø 0.8 mm 0700 200 176
Steel liner Ø 1.0/1.2 mm 0700 200 177
Steel liner Ø 1.2 mm 0700 200 178
10 m CW = cored wire
PTFE liner Ø 0.8 mm 0700 200 179
PA liner Ø 1.0 - 1.6 mm 0700 200 181
PA liner Ø 1.6 mm 0700 200 208
55 m coil
Nipple for PA liner 0700 200 209
fits PA liner 0700 200 181
and 0700 200 208
2 Feed roll Ø 0.8 mm - Ss, Al, Ms 0700 200 184
Feed roll Ø 1.0 mm - Ss, Al, Ms 0700 200 185
Feed roll Ø 1.2 mm - Ss, Al, Ms 0700 200 186
S
Feed roll Ø 1.6 mm - Al 0700 200 205
3 Wear insert Ø 0.8 - 1,6 mm Cu tube 0700 200 182
For straight swan neck
Wear insert Ø 0.8 - 1,6 mm Brass spiral 0700 200 183
For 45° swan neck
4 Tip adaptor M8 short 0460 819 001
S Replacing ordering no
0366 394 002
Tip adaptor M8 long 0458 224 001
5 Contact tip CuCrZr W0.8 M8 x 37 0468 502 003
Contact tip CuCrZr W0.9 M8 x 37 0468 502 004
Contact tip CuCrZr W1.0 M8 x 37 0468 502 005
Contact tip CuCrZr W1.2 M8 x 37 0468 502 007
S
Contact tip CuCrZr W1.6 M8 x 37 0468 502 010
S
6 Gas nozzle standard Ø 12 mm 0458 464 882
S
Gas nozzle conical Ø 9.5 mm 0458 465 882
Gas nozzle straight Ø 16 mm 0458 470 882
7 Spatter protection 0458 471 003
8 Gas nozzle “slip on” 0469 753 880
9 Spatter protection “slip on” 0469 539 001
10 Cooling sleeve “slip on” 0469 757 880
S = Standard delivery
