3.5 Component Locator
SECTION 3 SPECIFICATIONS
C37, C40,
C44,C47,
BUSS CAPACITORS 10.16
C101, C102,
C103, C104
BUSS CAPACITORS 10.16
PC1600 Components
Symbol Description Section # 4.
L1
INDUCTOR INPUT
9 REACTOR LINE 3 PHASE
L2 INDUCTOR OUTPUT
T1 TRANSFORMER MAIN 6
T2 TRANSFORMER CONTROL 2
BR1 BRIDGE RECTIFIER 110A 1600V 3
Q101,102 IGBT DUAL 150A 600V
5
Q103 IGBT 50A 1200V
D101,102 DIODE MODULE 100A 600V 7
PCB1 PC BOARD - CONTROL / DISPLAY 8
PCB2 PC BOARD - POWER 10
PCB3,4 PC BOARD - DRIVER BOARD 11
PCB5 PC BOARD - PILOT ARC DRIVER BOARD 13
PCB6 PC BOARD - REMOTE 18
PCB7 PC BOARD - EMC FILTER 50A 16
K1
RELAY SPST 24VAC 20A(110VDC) w/ MAG BLOWOUT
4
CONTACTOR 3P 40A 24VAC
M1 FAN 6” 230CFM 230V 2
SW1 SWITCH POWER 3P 60A 600V 1
SW2 SWITCH VOLTAGE SELECTOR 5
TS1 SWITCH THERMAL N/C 176°F
12
TS2 SWITCH THERMAL N/C 176°F - Solder
SOL1 SOLENOID 17
