Fascia, Fuel Bed and Glass Care
14
Step 1: Lift off the inner
fascia by pulling the base
of inner fascia out and
lifting it up and off.
Step 2: Unscrew the top glass retainer
and remove it. Take care that the
glass does not fall forwards at this
stage.
Step 3: Lift out glass and
place it carefully aside.
Continued...
Step 4: Take out log set / Fuel bed
media and gently brush any soot from
the fuel bed with a soft hearth brush.
The burner tops can be vacuumed
too.
