Clearances
ST900 Mantle Clearances
If any part of the installation (mantle, wall
or cavity) is constructed from
COMBUSTIBLE materials, the diagram
below shows the maximum allowable size
for mantles or protruding surfaces
mounted above an ST900
The material that the wall and mantle are made from will also affect
the operating temperature of the TV so it is the customers
responsibility to satisfy themselves that their TV mounting and
mantle design will not exceed the listed maximum operating
temperature of their electronic goods.
7
If the entire installation (mantle, wall and
cavity) is constructed from NON-
COMBUSTIBLE materials, then the
clearances to mantles or protruding
surfaces mounted above an ST900 may
be as shown by the shaded area in the
diagram below
