Technical Data
4. Technical Data
4.1 General Technical Data
Power supply voltage nominal voltage 24 V/DC ±10%,
current consumption (24 V, 20 °C): typical: 120 mA
Connectors
24V
CAN
DIAG
PORT1,
PORT2
InRailBus
24V-power supply voltage
(X1, 4-pin COMBICON-plug with spring-cage connection)
CAN bus interface
(X2, 5-pin Phoenix Contact MC 1,5/5-GF-3,81)
DIAG-interface (X3, USB-socket type B)
PROFINET IO-interface PORT1, PORT2 (X4,
2x RJ-45-socket with integrated transformer and LEDs)
CAN bus interface and power supply voltage via InRailBus
(X5, 5-pin ME-MAX-TBUS-connector, accessories)
Temperature range 0...50 °C ambient temperature
Humidity max. 90%, non-condensing
Dimensions width: 22.5 mm, height: 99 mm, depth: 114.5 mm
(without connectors)
Weight 130 g
Table 3: General data of the module
4.2 Microcontroller
Microcontroller ERTEC200, 150 MHz
Memory
SDRAM: 32 MB
NOR-Flash: 4 Mbyte
SPI-EEPROM 128Kbit
Table 4: Microcontroller unit
