Correct Wiring of Electrically Isolated CAN Networks
6.6 Examples for CAN Cables
esd recommends the following two-wire and four-wire cable types for CAN network design. These
cable types are used by esd for ready-made CAN cables, too.
6.6.1 Cable for light industrial Environment Applications (Two-Wire)
Manufacturer Cable Type
U.I. LAPP GmbH
Schulze-Delitzsch-Straße 25
70565 Stuttgart
Germany
www.lappkabel.com
e.g.
UNITRONIC ®-BUS CAN UL/CSA (1x 2x 0.22)
(UL/CSA approved) Part No.: 2170260
UNITRONIC ®-BUS-FD P CAN UL/CSA (1x 2x 0.25)
(UL/CSA approved) Part No.: 2170272
ConCab GmbH
Äußerer Eichwald
74535 Mainhardt
Germany
www.concab.de
e. g.
BUS-PVC-C (1x 2x 0.22 mm²) Order No.: 93 022 016 (UL appr.)
BUS-Schleppflex-PUR-C (1x 2x 0.25 mm²) Order No.: 94 025 016 (UL appr.)
6.6.2 Cable for heavy industrial Environment Applications (Four-Wire)
Manufacturer Cable Type
U.I. LAPP GmbH
Schulze-Delitzsch-Straße 25
70565 Stuttgart
Germany
www.lappkabel.com
e.g.
UNITRONIC ®-BUS CAN UL/CSA (2x 2x 0.22)
(UL/CSA approved) Part No.: 2170261
UNITRONIC ®-BUS-FD P CAN UL/CSA (2x 2x 0.25)
(UL/CSA approved) Part No.: 2170273
ConCab GmbH
Äußerer Eichwald
74535 Mainhardt
Germany
www.concab.de
e. g.
BUS-PVC-C (2x 2x 0.22 mm²) Order No.: 93 022 026 (UL appr.)
BUS-Schleppflex-PUR-C (2x 2x 0.25 mm²) Order No.: 94 025 026 (UL appr.)
INFORMATION
Ready-made CAN cables with standard or custom length can be ordered from esd.
