ESDEC Clickfit Evo - Cutting Mounting Rails to Required Size; Optional: Rail Couplers

11
2 CUTTING MOUNTING RAILS TO REQUIRED SIZE
1 DETERMINE THE LENGTH OF THE MOUNTING RAILS BASED ON THE SOLAR PANELS
20-35 mm
20-35 mm
12 mm
4
Measurethesolarpanelsandallowanadditional12mmbetweeneachsolarpanelfortheuniversalmoduleclamp.Allow
anadditional30mmoneachsideformountingtheendclampandendcap.
4
Calculatetheminimumlengthofthemountingrails:(panelsize+12mm)xnumberofpanels-12mm+(2x30mm)
4
Iftheoverhangissmallerthan250mm,keepaminimumof20mmtoamaximumof35mmraillengthoverhangfor
mountingtheendcap(art.no.1008060(-B)).
2 OPTIONAL: USE COUPLERS TO CONNECT THE MOUNTING RAILS
