ESDEC Clickfit Evo - Tighten Hanger Bolt Nuts; Attaching the Mounting Rails; Aligning Click Connections & Adapters

17
9 TIGHTEN THE NUT ON THE TOP OF THE HANGER BOLT
4
UsethecrosshairsontheadapterforagoodbasicpositionoftheEVOclickconnectionandtocompensateforanyroof
irregularities.
Diameter of hanger bolt Tightening torque
M10 Minimumof25Nm
M12 Minimumof40Nm
4 ATTACHING THE MOUNTING RAILS
1 USE THE NUTS TO ALIGN THE CLICK CONNECTIONS AND ADAPTERS IN THE DIFFERENT AXES.
4
Arethehangerboltsnotproperlyalignedinrelationtoeachother?Usethemountingrailtoadjustthehangerbolts.
Loosenoneorbothnutshalfaturnandclickthemountingrailintotheclickconnections.Therigidityoftherailensures
thattheadaptersandclickconnectionssetthemselvesintothecorrectposition.Thenretightenthenuts.
M10:Minimumof25Nm
M12:Minimumof40Nm
