PRODUCT INFORMATION
INTENDED USE
TheClickFitEVOmountingsystemforsolarpanelsonstandingseamroofsisdesignedformountingsolarpanelsonpitched
roofs.Withthismountingsystem,solarpanelscanbepositionedontheroofeitherwiththeshortsideatthebottom
(portrait)orwiththelongsideatthebottom(landscape).
IMPROPER USE
Themountingsystemisnotsuitableforuseontypesofroofotherthantheonespecied.
SPECIFICATIONS
Orientation of solar panels Portraitandlandscape
Frame height of solar panel 29-50mm
Maximum area of solar panels 2.6m
2
Maximum eld size Forhorizontalandverticalrails:15mpersegment
Roof material
Bitumen(insulatedandnon-insulated)
EPDM(insulatedandnon-insulated)
3
ThethermaleectofsometypesofEPDMandbitumenroongcanhavea
negativeeectonthewaterproong,causingitcannotbeguaranteedon
everyroof.ConsulttheroongsuppliertodeterminewhethertheClickFit
EVOhangerboltscanbeusedwithouttakingadditionalsteps.
Corrugatedsheets
3
Onacorrugatedroofwithstandardcorrugationtype177/51(NENEN494),
usetheClickFitEVOcorrugatedsheetbracket(articlenumber1008090).At
www.esdec.comyouwillndthecorrespondingmanual.
Arabic tiles
Sheet steel
Roof structure
Purlins
Trusses
Engineeredwoodboards
Roof pitch 7.1-60°
Maximum roof height
4
SubjecttoEurocodeguidelinesandnationaladditions.Usethecalculator
to calculate the possibilities of your project.
Edge zone
30cmdistancetotheridge,30cmtothesideoftheroofand30cmtothe
gutter.
3
Enterthedatainthecalculator,soyouaresureofchoosingtherightsystemfortheterraincategory,snowloadsand
windzonethatappliestoyourproject.
4
Dependingontheroofandtheresultobtainedfromthecalculator,youcanlayseveralsegmentswithsolarpanelsnextto
eachother.Alwaysleaveaminimumof10mmofspacebetweensegmentstoallowforexpansionoftheroof.
4
Ifyourprojecthasdierentspecicationsthanthese,pleasecontactEsdec.
REQUIREMENTS FOR THE WORK ENVIRONMENT
Theroofisingoodcondition.
Theroofconstructionhassucientbearingcapacitytosupporttheinstallation,takingintoaccountwindandsnow
loads.
