INSTALLATION
1 PREPARATION
1 INSPECT THE ROOF
Theroofisingoodcondition.
Theroofconstructionhassucientbearingcapacitytosupporttheinstallation,takingintoaccountwindandsnow
loads.
3
ThethermaleectofsometypesofEPDMandbitumenroongcanhaveanegativeeectonthewaterproong,
causingitcannotbeguaranteedoneveryroof.ConsulttheroongsuppliertodeterminewhethertheClickFit
EVOhangerboltscanbeusedwithouttakingadditionalsteps.
2 CHECK THE PROJECT PLAN AND COMPONENTS
Checktheprojectplan.Istherenoprojectplan?Thencreateoneintheonlinecalculatorbeforestartinginstallation.
Checkthatallcomponentsarepresent(page5).
Determinethepositionofthehangerbolts.Usethepurlinsortrussesifpresent.
3 MAKE SURE ALL THE REQUIRED TOOLS ARE AT HAND
General
Markerorchalk Brush Tape measure Hacksaw Adjustable pliers
Cordless
screwdriver
Torque wrench
Ratchet with
hexagonsocket
S13
Open-end wrench
(2x)
Masticgun
Hanger bolt M10 Hanger bolt M12
Drill through roong material 12.5mm 14mm
Predrill holes in roof structure 5mm 7mm
Hexagon socket S7 S10
Open-end wrench S15 S19
