ESDEC Clickfit Evo - Mounting the Following Panels; Installing Module Clamps; Sliding Panels into Clamps

23
7 MOUNTING THE FOLLOWING PANELS
Optional:Repearsteps6.1.ClicktheAuxiliarysetonthepaneland6.2.Clickthecablesofthepanelrmlyintothe
cable clamp.
1 CLICK THE UNIVERSAL MODULE CLAMP ON THE RAILS
2×
4
Installthemoduleclampwiththedrainagechannelofthemoduleclamppointingdownwards.
Repeatstep6.7.Placethepanelontherails
2 SLIDE THE PANEL AGAINST THE CLAMPS
