ESDEC Clickfit Evo - Placing Rails in Connections; Securing Rails (Vertical Mounting)

18
2 PLACE THE MOUNTING RAIL IN THE CLICK CONNECTION.
3 CLICK IN THE MOUNTING RAILS
4 FOR VERTICAL MOUNTING: SECURE THE MOUNTING RAILS TO THE CLICK CONNECTIONS
HEX
SW-10
4
Securethebottomclickconnectionwithaself-drillingscrew.Skiptwoclickconnectionsandthenscrewdownthefourth
click connection. Repeat until the top click connection.
