ESDEC Clickfit Evo - Insert Hanger Bolts & Harden; Seal Screw Holes

15
5 INSERT THE HANGER BOLT AND ALLOW CHEMICAL ANCHOR TO HARDEN.
4
Alignthehangerboltswitheachother.
6 TIGHTEN THE NUT SO THAT THE RUBBER SEAL DEFORMS AND THE SCREW HOLE IS SEALED
7 SEAL THE HOLE
Bitumen roof material:
• Tixophaltekit(articleno.
1003900)
• HangerboltwasherRVS80
mm(articleno.1003070)
EPDM roof material:
• EPDMkit(articleno.
1008086)
• HangerboltwasherRVS80
mm(articleno.1003070)
Arabic tiles:
• Waterproongkit(not
included in scope of
delivery)
