Kongsberg X-series

13. Tool inserts

Knife Blades are extremely sharp.

Take care when handling Knife Tools.

13.1. Ball Point Pen

The Ball Point Pen tool is available for pen

drawing.

Tool pressure is adjustable by a knob on top of the

tool.

Ball Point Pen tool is prepared for Space Pen

reﬁlls.

Tool assembly and pressure adjustment

A - Inner sleeve.

The ball point pen reﬁll is ﬁxed inside the sleeve

using a screw. Use Allen Key, 3 mm.

B - Sleeve holder with spring and pressure

adjustment knob.

Adjust tool pressure using the screw C.

Lock the adjustment screw using the locking knob

Tool Adjustment

For this tool, complete the following adjustments:

128
