ESP MAGPRO16 - Appendix B

MAGPRO16 Addressable Fire Alarm Panel – Installation and Programming Manual
50
Earth Fault function DISABLED
The Earth Fault indication is disabled.
Sounder Disabled
The Sounders are disabled.
Fire Brigade Output Disabled
The fire output is disabled.
Fire Protection Output Disabled
The extinguishing output is disabled.
Fault Output Disabled
The fault output is disabled.
Zone In Test
The zone is in test mode.
Transmitting device active
The Fire output is activated.
Extinguishing output active
The Extinguishing output is activated.
Sirens active
The sounders are activated.
User log off
Maintenance level exit.
Installer log off
Installer level exit.
User log on
Maintenance level entry.
Installer log on
Installer level entry.
High Resistance Disabled
The indication for high battery resistance is disabled.
Total loss of Power
The mains powers supply is lost.
Buzzer Disabled
The internal buzzer is disabled.
Network Break
Redundant network breakdown.
Loop Device Disabled
The loop device is disabled.
Chamber Fault
Fault in the detector.
Clean Me Now
Dirty detector chamber.
Loop Device Input Fault
Fault in loop device input.
Loop Device Output Fault
Fault in loop device output.
Alarm
Fire signal from detector.
PreAlarm
Fire signal from detector in 2DEVICES or DOUBLE operation mode for zone.
Test Fire
Fire signal from tested detector.
Loop Device Type Error
A different than the expected type of device has been detected at the address.
Loop Device Fault
The device does not respond (lost or damaged).
Double Address
More than one device with the same address in the loop.
Evacuate
Activated Call Point or EVACUATE button on the panel.
Log Fault
The Log file event is lost or damaged.
APPENDIX B
Table: Text and symbols for introducing device and zone names.
In device or zone name entering mode, every pressing of up/ down arrow button changes the entered letter or symbol.
When moving to the next new position the entering starts from the begging of the table.
[
!
”
#
$
%
&
‘
(
)
*
+
,
-
.
/
0
1
2
3
4
5
6
7
8
9
:
;
<
=
>
?
@
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
[
]
^
_
`
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z
