MAGPRO16 Addressable Fire Alarm Panel – Installation and Programming Manual
6
 16 groups for zones’ organization
 5 monitored potential outputs:
o SND1 (Sounder 1)
o SND2 (Sounder 2)
o FIRE
o FAULT (In case of Fault event the output is deactivated.)
o EXT (Extinguishing/ Fire Protection – An output for sending an fire alarm signal to automatic fire
extinguishing system)
 3 specialized inputs:
o In AmC* (Input Alarm Confirmation)
o In PC* (Input Protection Alarm Confirmation)
o In FP* (Input Fault Protection Panel)
* Covers the requirements on standard VdS 2540
 4 non-monitored, programmable relay outputs with parameters: 15A@24VDC
 Display – letter and digits LCD module (4 rows х 40 symbols)
 Built-in real time clock, supported from integrated lithium battery - 3V, CR3032 type
 Memory log file for up to 10240 system events
 Comprehensive day/night mode facility
 2 Steps of alarm levels (T1 and T2)
 Supports external thermo printer
 Multilanguage support for operation menus
 Easy software update via computer or USB drive
 Designed according the requirements of EN54-2/4
 Metal box cabinet for wall mounting: bottom (306х412х81mm) and cover (310х416mm)
1.2.2 Possible Hardware Configurations
 Minimal Configuration
o Control panel (main PCB with one built-in loop controller)
o Indication (indication PCB with mounted LCD module)
o Power supply source
 Maximal Configuration
o Control panel (main PCB with one built-in loop controller)
o Indication (indicator PCB with mounted LCD module)
o Power supply source
o MAGPRO16-L250 Loop controller (for the second loop)
o LAN Communication module
o RS485 Redundant Network controller
1.2.3 Environment
 Degree of protection: IP30
 Operation temperature: -5ºС up to +40ºC
 Relative humidity: up 95% (without condense)
 Storage temperature: -10ºС up to +60ºC
 Weight (without the battery): ~ 4.2 kg.
1.2.4 Electrical Characteristics
Earth Connection
The earth connection has to be realized in accordance with the rules for the electrical safety with the total resistance in
the circuit lower than 10Ω. It is mandatory to connect the main power supply cable to the middle input of the fire panel
terminal – see also item 2.4 Main power connection.
ATTENTION: Do not instal the fire panel near power electromagnetic fields (radio equipment,
electric motors, etc.)!
