Espressif ESP8266 Manual

#
2. Architecture of the Demonstration
2. Architecture of the
Demonstration
The architecture of the ping test demonstration is as follows:
•
When the ESP8266 runs in SoftAP mode, the architecture of the ping test
demonstration is as Figure 2-1 shows.
#
Figure 2-1. ESP8266 Running in SoftAP Mode
•
When the ESP8266 runs in Station mode, the architecture of the ping test
demonstration is as Figure 2-2 shows.
#
Figure 2-2. ESP8266 Running in Station Mode!
Espressif
# /#2 19
2016.09

Espressif ESP8266 Specifications

General

Digital I/O Pins	17
Analog Input Pins	1
Wi-Fi	802.11 b/g/n
Operating Voltage	3.0V - 3.6V
Clock Speed	80 MHz / 160 MHz
Operating Temperature	-40°C to 125°C
Dimensions	24mm x 14mm
Processor	Tensilica L106 32-bit micro controller
