Essilor Instruments SL 650 User Manual

U SER MANUAL > I NSTALLATION / C ONNECTION
The limited slot on the air socket should be aligned corresponded slot when
plugging and unplugging. Do not force the plug.
5
Place the gas shield directly on the gas shield screw
6
The 4-pin aviation plug of the chin-rest is connected to the “Output” on the base of the slit lamp
microscope; the power adapter is connected to the “Input” on the base of the slit lamp microscope.
USB3.0 slave
interface
Power
input
Power
output
USB2.0 slave
interface
USB3.0 host
interface
SL650L - Slit lamp microscope > V1 - 10-2021 - CE 15
Gas shield
