Application
Connection to LSS4 Panels
LSRA(C) LSRA(C) LSRA(C) LSRA(C)
1324
PT1-S PT1-SPT1-S PT1-S
RS-485 COMMUNICATIONS
LSS4
TB4
4500' (1372 M) MAX.
#18 AWG
TWISTED PAIR
[XMDN-007.CDR]
Figure Chapter 2-5: LSS4 to Annunciator One Line Diagram
When configured for use with an LSS4 panel, up to 52 messages can
be stored in each annunciator. An LSS4 panel can support up to four
annunciators in any combination, including RSA4 series annunciators.
2.4
LSRA Installation, Operation, Maintenance, and Configuration Manual
