EST LSRA - Controls and Indicators Overview

Programming
User Operations
XMDND1.CDR
LCD Display
System status information displayed here
Life Safety Remote Annunciator
Reset Switch
Returns panel to normal
Back Switch
Displays previous message
Next/Acknowledge Switch
A
cknowledges current message &
displays next message
Alarm Silence Switch
Push to turn off audible alarm signals
Drill/All Call Switch
Initiates fire drill or activates
all fire alarm signals
Trouble Buzzer Silence Switch
Silences internal trouble buzzer
Trouble Buzzer Silenced Indicator
S
h
o
w
s
b
u
zz
e
r
h
a
s
b
e
e
n
s
il
e
n
c
e
d
Drill/All Call Active Indicator
Shows fire drill in progress or
all fire alarm signals active
A
l
a
r
m
S
i
l
ence
d
I
n
d
i
ca
t
o
r
Yellow when alarm signals turned off
System Normal Indicator
Green when system is normal
System Alarm Indicator
Red when fire detected
System Supervisory Indicator
Yellow when an ancillary system
is in trouble
System Trouble Indicator
Yellow when fire alarm panel
is in trouble
Figure Chapter 5-1 LSRA-C Controls and Indicators
Overview
Each LSRA(-C) recalls message information stored in its internal
memory in response to the zone information it receives from the
CM1N, CM2N, or DCPU. Each LSRA(-C) is buffered for 1,000
messages, and messages require local acknowledgment.
5.2
