Programming
CONVERT.EXE Utility Program Template
The CONVERT.EXE Utility Program utilizes a Command Line
Compiler for configuring the LSRA(-C) on IRC-3, LSS, and FCC
systems. The compiler allows you to create a configuration file and
download it to the LSRA(-C). Template examples when using the
CONVERT.EXE utility program follow:
LSRA application for IRC-3 system
; LSRA source file template for IRC-3 LSRA application.
; Definition of commands
:
;
; MAX NODES - Must be set to 64 for IRC-3 operation.
; ANNUNCIATION - Must be set to GLOBAL for IRC-3 operation.
; EXTERNAL MSG - Must be set to INACTIVE for IRC-3 operation.
; FIRE SYSTEM - Must be set to IRC-3 for IRC-3 database.
; MSG ROUTE - Must be set to ALL for IRC-3 operations.
; NETWORK CLASS - Communications class. The number of RS485
; connections as defined by IRC-3 system.
; NETWORK BAUD - The communications baud rate for IRC-3 connection.
; GEO - Determines display operations for given market.
; PRINTER TYPE - Local printer selection.
; PRINTER BAUD - Selects baud rate at which to communicate with
; serial printer.
; SWITCH MASK - Selects which switches are active for both switch
; positions.
; CURRENT ID - Defines the base address of the LSRA.
; ERROR ACTION - For IRC-3 applications, this field defines the
; number of consecutive panel addresses used.
; This number can be 0100, 0200, 0300 or 0400.
;:::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::
MAX NODES 64 ; 01 - 64
ANNUNCIATION GLOBAL ; LOCAL - GLOBAL
EXTERNAL MSG INACTIVE ; ACTIVE - INACTIVE
FIRE SYSTEM IRC-3 ; FCC A, FCC B, IRC-3, LSS
MSG ROUTE ALL ; ALARM, SUPERVISOR, TROUBLE, ALL
NETWORK CLASS B ; A, B
NETWORK BAUD 9600 ; 2400, 4800, 9600, 19200
GEO USA ; USA, CANADA, EUROPE
PRINTER TYPE NONE ; NONE, FORM, STRIP
PRINTER BAUD 9600 ; 2400, 4800, 9600
SWITCH MASK FF ; [0][0] - [F][F] [ ENABLE ][ DISABLED ]
CURRENT ID 05 ; 05 - 63
ERROR ACTION 0400 ; 0?00 ?= number of panel addresses.
;
; Message type definitions:
; AA = Alarm SS = Supervisory TT = Trouble XX = Status zone.
;
; 0 1 2 3 4
; 01234567890123456789012345678901234567890
message AA0509 Message associated with output 0509 ;
LSRA Installation, Operation, Maintenance, and Configuration Manual 4.33
