Programming
IRC-3(FCC/PCPU) and FCC/DCPU Phase 2 - Parameter
Entry for Selected Display (Individual Annunciator
Configuration)
After the network parameters have been entered, each LSRA must be
configured (phase 2). Press
Tab to advance to the “Parameter Entry for
Selected Display” menu.
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
PARAMETER ENTRY for SELECTED DISPLAY
Current Project File: Base Address: 5 IRC-3
Project Name: Printer:
Location: Baud Rate:
Active When Enabled:
Active When Disabled:
L Enter Location P Select Printer
E Select Active when Keyswitch Enabled B Select Printer Baud Rate
D Select Active when Keyswitch Disabled T Transmit to Display N
Set to No Switch Panel H Print to Hard Copy (or File)
INSTRUCTIONS
Press Press letters L, E, D, P, or B to alter the corresponding item.
Press letters N, T, H, or F to execute the action stated.
Press TAB to move to the next screen and enter or edit messages.
The selection shown above will be saved.
Press ESC to return to prior menu - selection shown will be saved.
IRC-3 Selected Display Menu
4.10
LSRA Installation, Operation, Maintenance, and Configuration Manual
