Programming
Sample Alarm Message:
SCREEN LABEL M023
FIRE ALARM 000052
Custom Label entered
thru the IBM PC
= Screen Label and # of unacknowledged messages
= Alarm Type and Alarm zone address
= Custom message on two lines
LEDs
Table Chapter 5-1: LED Indicators
Indicator USA Canada Europe
Normal LED Steady Steady Steady
Alarm LED Steady Flashing until acknowledged Steady
Trouble LED Steady Flashing until acknowledged Steady
Supervisory LED Steady Flashing until acknowledged Steady
Buzzer
UnAck Message
Trouble
Pulses
Steady
Pulses
Steady
Pulses
Steady until silenced, then
1/2 second pulse as a
silenced reminder; every 14
seconds, when silenced.
LED Indicators
NORMAL LED
The normal LED illuminates when the system to which the LSRA-C is
connected has no faults or off-normal conditions.
ALARM LED
The alarm LED illuminates when the host system to which the LSRA-
C is connected is in an alarm condition.
SUPERVISORY LED
The supervisory LED illuminates when the LSRA-C receives a
supervisory alarm which is in its database. A common supervisory (no
message in display) turns on the supervisory LED, but does not require
silencing.
TROUBLE LED
The trouble LED illuminates when the LSRA-C receives a trouble
which is in its database. A common trouble (no message in display)
turns on the trouble LED, but does not require silencing.
5.4
LSRA Installation, Operation, Maintenance, and Configuration Manual
