Universal interface
ET System electronic GmbH 13
LIMI - Limit I
a
With this command the user can read the maximum adjustable current limiting.
Example: 300A unit, I
limit
was adjusted to 200 A via configuration menu
LIMI
Query of maximum adjustable current
LIMI,200.0A
Unit answers: I
limit
= 200,0 A
LIMU - Limit U
a
Reads maximum adjustable voltage limitation. This command requests the previously defined maximum output
voltage.
Example: 300 V unit was adjusted to 200 V via configuration menu
LIMU
Query of maximum adjustable current
LIMU,200.0V
Unit answers: U
limit
= 200.0 V
MI[,<Nr>] - Measure I
a
This command measures the present output current.
Example:LAB/HP/E 15100 (100VDC; 150A)
GTR
Remote operation
OVP,140
Over voltage protection 140 V
UA,100
Output voltage 100 V
IA,50
Output current 50 A
SB,R
Output open
MI
Measures present output current
MI,50.0A
Unit answers: 50,0 A
MU[,<Nr>] - Measure U
a
This command shows the measurement value of the present output voltage.
Example:LAB/HP/E 15100 (100VDC; 150A)
GTR
Remote operation mode
OVP,140
Over voltage protection 140 V
UA,10
Output voltage 10 V
IA,1
Output current 1 A
SB,R
Output open
MU
Measures present output voltage
MU,10.0V
Unit answers: 10,0 V
