Technical Specifications
2 ET System electronic GmbH
TECHNICAL SPECIFICATIONS
INPUT SPECIFICATION:
Device Power
5kW 10kW 15kW 20kW 30kW 45kW 60kW
Connection
Input 1P/230
Input 3P/200
Input 3P/209
Input 3P/400
Input 3P/440
Input 3P/480
Max allowed non
symetry
(3P-Systeme)
Input current
1,2
1P/230 Modell
33 A eff
X
14
X
14
X
14
X
14
X
14
X
14
Input current
1,2
3P/200 Modell
25 A eff 50 A eff 74 A eff 99 A eff 148 A eff 221 A eff
295 A eff
Input current
1,2
3P/208 Modell
23 A eff 46 A eff 69 A eff 92 A eff 138 A eff 207 A eff
276 A eff
Input current
1,2
3P/400 Modell
11,5 A eff 22,9 A eff 34,4 A eff 45,8 A eff 68,7 A eff 103,1 A eff
137,5 A eff
Input current
1,2
3P/440 Modell
11 A eff 21 A eff 32,5 A eff 42 A eff 63,5 A eff 95 A eff
127 A eff
Input current
1,2
3P/480 Modell
10 A eff 19,5 A eff 30 A eff 39 A eff 58 A eff 87 A eff
117 A eff
Nominal current
Internal Fuse
3P/400 Modelle
15 A 30 A 45 A 60 A 90 A 135 A 180 A
Recommended Supply
breaker 3P/400 Model
(value and curve)
16A
Type D/K
32A
Type D/K
63A
Type D/K
63A
Type D/K
80A
Type D/K
120A
Type D/K
150A
Type D/K
Leakage current
cos phi
Harmonic content
3
Efficiency Type
50Hz = 72% / 100Hz = 2% / 150Hz = 0,9% / 200Hz = 0,1% / 250Hz = 11% / 350Hz = 0,6%
94%
<153 A
<229 A
3 x 440VAC (396-484VAC 47-63Hz)
3 x 480VAC (432-528VAC 47-63Hz)
< 3%
<305
<35 mA
>0,7
Inrusch
transientcurrent
2
<25 A
<51 A
<76 A
<102 A
3 x 400VAC (360-440VAC 47-63Hz)
LAB/HP/E
3 Leitungen (1P+N+E) / 5 Leitungen (3P+N+E)
1 x 230VAC (207-253VAC 47-63Hz)
3 x 200VAC (180-220VAC 47-63Hz
3 x 208VAC (187-229VAC 47-63Hz)
1 For nominal current and voltage
2 For nominal input voltage
3 Total harmonic distortion input current ([%] I in)
4 250A is the maximum possible current for an 5kW Unit
5 If the ripple is not specified, maximum allowed ripple is 0,2% of F.S.
6 The measurement of the peak peak ripple is strongly dependent of the measurement setup
7 The given accuracy is also all interfaces valid
9 Higher number is possible, ask manufacturer
11 The ripple measurment methode of ET-System is specified at application note „ET Ripple-Spec. (Page 32)
12 The ripple specification is reservation to change on the part of manufacturer
13 Device is at the moment only available with highspeed output (Low output cap.)
14 Not as standard Unit available
