Et system LAB-HP/E Series - Output Specifications

Technical Specifications
ET System electronic GmbH 3
OUTPUT SPECIFICATION:
Static Regulation
Line Regulation Voltage
Line Regulating Current
Load Regulation Voltage
Load Regulation Current
Dynamic Response Time
@Load Step 10 - 90%
Output Voltage [V]
15 20 25 35 40 45 70 80 100 150 300 600 800 1000 1200 1500
HP/E 5KW Unit [A]
x 250 200 150 125 120 75 65 50 35 17 8,5 6,5 5 4,2 3,3
HP/E 10KW Unit [A]
x 500 x 350 250 250 175 130 100 75 40 17 13 10 8 6,6
HP/E 15KW Unit [A]
x 750 x x 375 x x 195 150 100 50 25 19 15 12 9,9
Voltage ripple (p-p)
20MHz
40
12
80
12
80
12
80
12
140
12
140
12
140
12
140
12
140
12
900
12
900
12
900
12
1000
12
1200 2500 2500
Voltage ripple (p-p)
300KHz
15
12
35
12
35
12
35
12
60
12
60
12
60
12
60
12
60
12
400
12
400
12
400
12
700
12
800 1500 1500
Voltage ripple (rms)
5
mV
20MHz
15 35 35 35 60 60 60 60 60 400 400 400 400 400 400 500
Voltage ripple (rms)
5
mV
300KHz
10
12
25
12
25
12
25
12
40
12
40
12
40
12
40
12
40
12
300
12
300
12
300
12
300
12
300 300 400
Current ripple (p-p)
Current ripple (rms)
Primary / Sekundary
DC - Output/ Earth
Primary / Earth
Rise time full Load
13
6 ms 6 ms 6 ms 6ms 12 ms 12 ms 12 ms 20 ms 20 ms 20 ms 20 ms 20 ms 40 ms 40 ms 40 ms 6 ms
Rise time no Load
13
5 ms 5 ms 5 ms 5 ms 10 ms 10 ms 10 ms 10 ms 10 ms 10 ms 10 ms 10 ms 10 ms 20 ms 20 ms 5 ms
Fall time full Load
13
15 ms 15 ms 15 ms 15 ms 20 ms 20 ms 20 ms 20 ms 20 ms 40 ms 40 ms 50 ms 60 ms 80 ms 100 ms 25 ms
Fall time no Load
Rel. Accuracy ±[%]
7
Voltage [V] 0,25
0,038 0,050 0,063 0,088 0,100 0,113 0,175 0,200 0,250 0,375 0,750 1,500 2,000 2,500 3,000 3,750
Current [A] 0,4
1,000 1,000 0,800 0,580 0,500 0,480 0,288 0,260 0,200 0,140 0,068 0,034 0,026 0,020 0,017 0,013
Voltage [V] 0,5
0,075 0,100 0,125 0,175 0,200 0,225 0,350 0,400 0,500 0,750 1,500 3,000 4,000 5,000 6,000 7,500
Max. Sens Voltage over
nominal Voltage
7
Max. Sens Voltage inside the
normal Voltage range
7
Resolution Voltage
Display
Voltage setting resolution
Resolution Current
Display
Current setting resolution
OVP
UI-Modus
100V - 999,9V
000.0
15V - 99,99V
00.00
10A - 99,99A
00.00
100A - 999,9A
000.0
1.000A - 9.999A
0000
Over Voltage Protection: is adjustable between 0% and 120% of Voltage full range
Voltage and Current operation mode: Voltage and current are setable
Device Function
OTP
Over Temperature Protection: if the internal heat sink tempearatury is go above 90°C
the divice will automaticaly shut down
Resolution
<0,4 % of F.S.
Ripple and Noise
11
Accuracy
3.000VAC
500VDC
2.000VDC
2.150VDC
Isolation
5 s unter 50VDC
Output speed
Relative Accuracy for Sens operation (worst case) [%]
1.000V - 1.500V
0000
0A - 9,999A
0.000
5% of F.S. (if higher voltage is needed ask manufacturer)
±1% of F.S.
OCP
Over Current Protection: is realised by the current set point.
The output current can not go over the set value
Regulation
± 0,1% of F.S.
± 0,02% F.S.
± 0,02% F.S.
± 0,05 % F.S. ± 2mV
± 0,05% F.S. ± 20mA
< 3ms
Other combinations of Voltage and Current also possible, ask the Manufakturer
Basic calculation of possible combinations are:
Pout = Vout x Iout / Pmax for one Unit 90KW / Cmax = 250A each 5KW
Output Current
<0,5 % of F.S.
