12. Advanced settings, customization
Adjust seat depth using lumbar angle, 3A
An extended seat depth is obtained by opening the back support
angle (hip) and following with the lumbar angle.
1. Adjust the back angle (see section “Adjusting the back support
angle 3A”).
2. Adjust the lumbar angle using the eccentric sleeve to the desired
back angle (see “Adjusting the back support height and lumbar
angle, 3A”).
3. If necessary, mount the seat extender (accessory).
Consider the risk of tipping.
Always check the setting of the anti-tip guard.
5 mm
Consider the risk of tipping.
Always check the setting
of the anti-tip guard.
Mount the seat extender
