12. Advanced settings, customization
Adjust the back support height, 2B
The back height is adjustable (see “The chair’s possibilities”). Loosen
the screws to adjust the back height. Tighten the screws.
Consider the risk of tipping.
Always check the setting of the anti-tip guard.
4 mm
8 mm
Adjust the back angle, 2B
The angle of the back support is continuously adjustable (see
“The chair’s possibilities”). The angle is adjusted by means of
the nut on the inside of the rear wheel mounts.
- Loosen the nut for one of the back posts, set the desired angle and
tighten.
- Adjust the other back post equally.
Check that the angle is the same on both sides by comparing
the distance between the back post and the arm support plate.
Consider the risk of tipping.
Always check the setting of the anti-tip guard.
13 mm
