ETC Installation Guide
ColorSource CYC v1.6
ColorSource CYC v1.6 Page 2 of 12 ETC
Environment
The ColorSource CYC operates in ambient temperatures of 0°C–40°C.
Electrical
• Operates between 100V and 240VAC at a frequency of 50/60Hz.
• Maximum power consumption is 160W.
• Up to 9 luminaires (15A max) may be linked via power thru connector
(10 luminaires total per circuit) when used with an R20 Relay Module
or Unison Echo
®
Relay Panel. Consult breaker trip curves when used
with other equipment. Requires power from a non-dimmable source.
• Inrush:
- 120V: 39A (first half-cycle)
- 240V: 74A (first half-cycle)
Typical power consumption
Note:
The ColorSource CYC is for indoor use only.
Note:
• Maximum recommended ambient operating
temperature: Ta = 40°C (104°F)
• Maximum anticipated external surface temperature
at 40°C ambient: Tmax = 110°C (230°F)
• External temperatures after 5 minutes of full-
brightness operation at 25°C (77°F) ambient:
49°C (119°F)
• External temperature (steady state achieved) at
25°C (77°F): 88°C (190°F)
100V 120V 230V
Idle Power/Current
1.66W/0.0414A 1.38W/0.04A 1.18W/0.0486A
Direct at Full/Current
133.7W/1.34A 132.6W/1.11A 130.4W/0.594A
