Changing the DMX control mode
You can set the DMX control mode for the fixture to one of four available
mode options.
1: Press any button to wake the display. The display shows the DMX
address.
2: Press and hold the Mode button for 3 seconds. The display shows the
current DMX control mode.
3: Press the Up and Down buttons to change the DMX control mode.
•
: 5-channel mode (intensity, red, green, blue, and strobe)
•
: Direct emitter control (intensity, red, green, blue, indigo,
lime, and strobe)
•
: 1-channel mode controls the intensity of preset 1 (defaults to
3200K White)
•
: RGB mode (red, green, and blue)
4: Press the Mode button to confirm your selection.
The display will automatically return to the DMX address after 10 seconds of
inactivity, and edits to the DMX control mode will not be saved. This cancels
unsaved changes.
DMX control channels
Note:
Direct mode (
) on the ColorSource CYC is not a
calibrated mode. As a result, you may see discrepancies
in color between fixtures. ETC recommends operating in
one of the calibrated modes.
DMX
Channel
(5 Channel)
(Direct)
(1 Channel)
(RGB)
1 Intensity Intensity Intensity Red
2 Red Red
Green
3 Green Green Blue
4Blue
Blue
5 Strobe Indigo
6
Lime
7
Strobe
