Echoflex Installation Guide
LED Fixture Controller (120-277 VAC)
Installation
Ensure that the junction box is clean and free of obstructions and that all
wiring is installed correctly. Review these instructions completely before
installing the controller.
Note:
Follow applicable NEC and local electrical code
requirements when installing and powering the controller.
Install ELED1 with Nipple
Mount the controller directly to the exterior of the junction box or panel
either at the electrical load or before the load in the circuit.
1. Locate the circuit breaker panel and terminate power to the circuit.
2. Remove the cover plate and other hardware from the junction box to
access the wiring.
3. Mount the controller.
4. Refer to the
Wiring Diagram on the next page
to connect the
controller to line power, neutral, and load wires. Use wire nuts on all
connections and individually cap any bare wires, except the orange
antenna wire.
5. Connect the gray and the violet wires to the driver or ballast’s
dimming interface (optional).
6. Replace the electrical box cover plate and restore power to the circuit.
Install ELED1 with Mounting Strap
Mount the controller to the exterior of a lighting fixture or appliance
using the supplied mounting strap.
Note:
Mounting inside a fixture or other metal cabinet will
reduce radio range performance.
1. Locate the circuit breaker panel and terminate power to the circuit.
2. Slide the mounting strap over the controller housing with the orange
antenna wire facing up. Hold the controller in place. The tooled strap
prevents the controller from sliding out.
3. Use a power drill to drive a 3/8 inch #8 screw through one of the
bracket’s mounting holes into the fixture. Repeat for the other
mounting hole.
4. Refer to the wiring diagram to connect the controller to line power,
neutral, and load wires. Use wire nuts on all connections and
individually cap any bare wires, except the orange antenna wire.
5. Ensure the antenna wire is not close to any metal surface (for
example: the lighting fixture metal housing).
LED Fixture Controller (120-277 VAC) Page 3 of 12 Echoflex
