8 Check that nothing leaks.
9 The machine is ready for use.
9.5 Drink selection labels
Be careful when moving the machine. The machine is
heavy, see 6.5.
• Consult the safety regulations, see 9.1.
• Remove the plug from the socket.
1 Access the machine.
2 Open the door with the key.
3 Remove the cover plate in the door.
4 The drink label is affixed in the door above the dispensing unit.
5 Remove the existing drink label.
6 Put the new drink label in place.
Ensure that all labels have been positioned correctly.
7 Close the door.
9.6 Replacing the inlet valve
1 Empty the boiler, see par. 9.3.
2 Remove the plate on the right side, see par. .
3 Disconnect the wiring from the inlet valve.
4 Disconnect the water hoses from the inlet valve.
5 Unscrew the two screws from the inlet valve.
6 Replace the inlet valve.
7 Connect the water hose to the inlet valve.
8 Connect the wiring to the inlet valve.
9 Restart the machine; see the restart procedure in par. 9.4.
Figure 9-2
Figure 9-3
