10 - Assembly Procedures
Parts needed:
(5) 5/16-18 x 1” Hex-head bolts
(5) 5/16” Flat washers
Open the grill:
Using the hex key (in hardware kit)
turn the four latches on the grill to
unlock it. Swing the grill open.
Secure the Left Module to the Base
with the five bolts and washers in the
slotted holes. (one hole not visible in
illustration because of grill)
2
1
To Next Page
