25809-02A
Lamp and Grill Replacement - 33
Lamp and Grill Replacement
Introduction
To be assured of maximum tanning effectiveness,
change lamps after approximately 600-800 hours
of use. Tanning will continue after this time but at
a slower rate. To ensure trouble-free operation of
your booth, replace the lamp starters whenever
the lamps are replaced.
Opening/Replacing Grill Shields
Each grill is secured in place by four quarter-turn
latches. The Left Module is shown at right. Using
the hex key (included in the hardware kit) remove
the floor. Then use it to unlock the grill. 1Swing
the grill open, 2lift it and 3pull the bottom out.
To replace the grill, insert the top hinge pin in the
hole at the top of the module, swing the bottom
pin into place and drop it down to engage the pin.
WARNING
Shock hazard.
Disconnect power before removing
any protective covers.
CAUTION
Be careful. The edges of the grill shield
may be sharp.
