25809-02A
14 - Assembly Procedures
Parts needed:
(1) Lower handle bracket
(3) #8-32 x 3/4” Phillips screws
Locate the three holes in the bottom
plate of the Right Module. Position
the Lower Handle Bracket underneath
the bottom plate and attach with the
three screws as shown.
Close and lock the grill.
To Next Page
