ETS SolarForce 652V - Page 26

25809-02A
24 - Assembly Procedures
Parts needed:
Blowers (box 6)
(4) 1/4-20 x 5/8” Phillips pan head bolts
The Blower assemblies hook on
the base and pivot into position
(see detail below). Secure them
in place with the bolts.
Plug the cables from the
booth into each Blower.
