EUCHNER CTM-LBI-BR Unicode Series - 8 Mounting

11
2525462-01-01/20 (Translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTM-LBI-BR
EN
8. Mounting
CAUTION
Safety switches must not be bypassed (bridging of contacts), turned away, removed or otherwise
rendered ineffective.
Ì Observe ENISO14119:2013, section 7, for information about reducing the possibilities for by-
passing an interlocking device.
NOTICE
Risk of damage to equipment and malfunctions as a result of incorrect installation.
Ì Safety switches and actuators must not be used as an end stop.
Ì Observe ENISO14119:2013, sections 5.2 and 5.3, for information about mounting the safety
switch and the actuator.
Ì Protect the switch against damage, as well as against penetrating foreign objects such as swarf,
sand and blasting shot, etc.
Ì Observe the min. door radii (see chapter 12.4.1. Dimension drawing for actuator A-B-A1-A1-… on
page 30).
Ì Observe the tightening torque for fastening the switch and the actuator (2,9Nm max.).
Ì The actuator’s plate must lie ush on the mounting surface.
Ì Actuator and safety switch must be mounted such that the actuator is correctly inserted into the
switch when the guard is closed.
