29
2525462-01-01/20 (Translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTM-LBI-BR
EN
12.3. Dimension drawing for safety switch CTM…
24
36
120
108
38,5
M12x1
12
25
38,5
14
28
35
50
R150
R400
Auxiliary release
(optional)
LEDs
∅ 4.5 (2x)
For M4 screw
Necessary minimum travel + permissible overtravel
Approach direction
Horizontal (h) 18 + 2
Min. door radius [mm]
