EUCHNER CTM-LBI-BR Unicode Series User Manual

Operating Instructions
Transponder-Coded Safety Switch CTM-LBI-BR
18
(Translation of the original operating instructions) 2525462-01-01/20
9.8. Connector assignment, Y-distributor for series connection to a BR evaluation unit
M12x1
max. 45
Ø 14,5
Strapping plug 097645
4-pin, plug
(gure similar)
Y-distributor with connecting
cable
158192 or 158193
Socket
Pin Socket
Pin Function
X2.1 U
B
X2.2 FO1A
X2.3 0V
X2.4 FO1B
X2.5 OD/C
Pin Function
X3.1 U
B
X3.2 FI1A
X3.3 0V
X3.4 FI1B
X3.5 OD/C
46
36
14,5
M12x1
14,5
M12x1
14,5
M12x1
45
15
45°
6
7
1
2 4
3
8 5
3 4
5 11 5
4 3 22
Y-distributor
157913
Socket
Connector assignment of safety
switch CTM-LBI-BR (8-pin plug)
and Y-distributor (8-pin socket)
Pin Function
X1.1 FI1B
X1.2 U
B
X1.3 FO1A
X1.4 FO1B
X1.5 OD/C
X1.6 FI1A
X1.7 0V
X1.8 nc
Pin Socket
15
45
42 44
14,5
18
M12x1
M12x1
14,5
M12
x1
14
45°
8
2 3
1
4
6
5
7
1
2
4
5
33
4
2
1
5
Length l
Order no.
Length
l [mm]
158192 200
158193 1,000
Pin Function
X2.1 U
B
X2.2 FO1A
X2.3 0V
X2.4 FO1B
X2.5 OD/C
Pin Function
X3.1 U
B
X3.2 FI1A
X3.3 0V
X3.4 FI1B
X3.5 OD/C
