EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 35 of 62
Parameters (1) AI Err Time 0 240 s 2
analog inputs time-out (after this time without
communication with an analog input, the
controller signals the analog input error)
Parameters (1) AO impulse 1 50 ms/10 20 cut phase pulse duration
Parameters (1) AO1 - - - - - - - - - 0-10V
kind of signal analog input 1
FAN = FAN (for cut phase module)
0-10V = 0-10 V
PWM = PWM (Pulse With Modulation)
Parameters (1) freq 10 2000 Hz 1000
frequency of the PWM signal of the analog
output 1
Parameters (1) Delay ph. 0 50 ms/10 0
displacement of the cut phase pulse of the
analog output 1
Parameters (1) AO2 - - - - - - - - - 0-10V
kind of signal analog input 2
FAN = FAN (for cut phase module)
0-10V = 0-10 V
PWM = PWM (Pulse With Modulation)
Parameters (1) freq 10 2000 Hz 1000
frequency of the PWM signal of the analog
output 2
Parameters (1) Delay ph. 0 50 ms/10 0
displacement of the cut phase pulse of the
analog output 2
Parameters (1) AO3 - - - - - - - - - 0-10V
kind of signal analog input 3
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (1) AO4 - - - - - - - - - 0-10V
kind of signal analog input 4
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (1) AO5 - - - - - - - - - 0-10V
kind of signal analog input 5
0-10V = 0-10 V
Parameters (1) AO6 - - - - - - - - - 0-10V
kind of signal analog input 6
0-10V = 0-10 V
Parameters (1) EEV_StepRate 25 1000 step/s 100 movement speed of the valve
