EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 36 of 62
Parameters (1) EEV_DrvMode 0 2 - - - 1
driving mode of the stepper motor
0 = full step 2 phases on
1 = full step 1 phase on
2 = half step
Parameters (1) EEV_DutyForce 50 100 % 1
duty cicle to avoid the overheating
100% = always forced movement
Parameters (1) EEV_OvrSteps 0 4900 step 2000
number of steps required to totally close the
valve
Parameters (2)
[ press button
RIGHT to
show it ]
I/O Timeout 1 240 s 60
time-out of the CANbus communication for
the test of the remote values of the I / O
(after this time without CANbus
communication, the I / O of the controller is
disabled)
Parameters (2)
[ press button
RIGHT to
show it ]
En. Prg Level - - - - - - - - - NO
enabling the access to the first level page
pressing a combination of buttons
YES = yes, operating as follows:
- keep pressed 3 s button
ENTER to gain access
to the first page of
level 1
- keep pressed 3 s
buttons ENTER and
ESC to gain access to
the first page of level 2
- keep pressed 3 s
buttons LEFT and
RIGHT to gain access to
the first page of level 3
Parameters (2)
[ press button
RIGHT to
show it ]
Password Indi - - - - - - - - - NO
connection among the passwords to gain
access to the levels
NO = one has not to set any
password to gain access to
levels lower than the one one
has already gained access
YES = one has to set a password to
gain access to each level
Parameters (2)
[ press button
RIGHT to
show it ]
Ena BkMem
RTC
- - - - - - - - - YES
enabling the real time clock and the backup
memory
